Product Overview
CARBIDE END MILL FOR ALUMINIUM
For Cutting of Aluminium. Helix Angle 45 Degree. Sizes 1mm to 12mm
ITEM(S)
- 1 Pc. 3 Fluted Carbide Square End Mill
SPECIFICATION - Uncoated Micrograin Carbide Of Hardness HRC50
- 3 Fluted Center Cutting (For Plunging) Square End Mill
- Helix Angle 45 Degree
- For Dry Machining At High Speed
- Available Dimensions (MM):
| Cutting Ø | Shank Ø | OAL | Cutting L |
|---|---|---|---|
| 1 | 4 | 50 | 4 |
| 1.5 | 4 | 50 | 6 |
| 2 | 4 | 50 | 8 |
| 2.5 | 4 | 50 | 10 |
| 3 | 4 | 50 | 12 |
| 4 | 4 | 50 | 14 |
| 5 | 6 | 50 | 16 |
| 6 | 6 | 50 | 19 |
| 8 | 8 | 60 | 22 |
| 10 | 10 | 75 | 25 |
| 12 | 12 | 75 | 25 |
PRODUCT PHOTO
|
|
